CKRD4830
RoHS
RoHS compliant
RoHS compliantPackage SSR with Integrated Heat Sink
Category Relays / Solid State Relays
Description
CRYDOM CKRD4830 Solid State Relay, SPST-NO, 30 A, DIN Rail, Cage Clamp, 48 Vrms, 530 Vrms
PDF
/
Buying Options
Total Price: USD $680.75
Unit Price: USD $680.74815
≥1 USD $680.74815
Inventory: 208
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount DIN Rail, Panel
Mounting Type DIN Rail
Package / Case SSR with Integrated Heat Sink
Number of Pins 4
Technical
Packaging Bulk
Published 2008
Series CKR48
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Screw
Max Operating Temperature 80°C
Min Operating Temperature -40°C
Depth 22.5mm
Current Rating 30A
Termination Style Screw Terminal
Voltage - Rated AC 530V
Approval Agency CE, CSA, UL, VDE
Output Voltage 530V
Output Type AC, Zero Cross
Operating Supply Voltage 530V
Circuit SPST-NO (1 Form A)
Insulation Resistance 1GOhm
Voltage - Input 4V~32VDC
Output Current 30A
Throw Configuration SPST
Max Voltage Rating (DC) 32V
Max Output Voltage 530V
Relay Type Relay
Voltage - Load 48V~530V
Input Current 12mA
Load Current 30A
Isolation Voltage 4kV
Dimensions
Height 99mm
Length 81.9mm
Width 22.5mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
