B53TP25C-10 image
Favorite
B53TP25C-10 image
Favorite

B53TP25C-10

Sensata-Crydom
RoHS
RoHS RoHS compliant
Package Module
Category Relays / Solid State Relays
Description RELAY SSR IP20 25A 3PHAS PNL MNT
PDF
/
Buying Options
Total Price: USD $605.82
Unit Price: USD $605.815386
≥1 USD $605.815386
≥200 USD $241.724584
≥500 USD $233.647623
≥1000 USD $229.656407
Inventory: 8091
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Length 101.3mm
Height 79.7mm

Technical

Min Supply Voltage (AC) 48V
Max Supply Voltage (AC) 530V
Isolation Voltage 4kV
Load Current 25A
Input Current 16mA
Max Input Current 16mA
Voltage - Load 48V~530V
Relay Type Relay
Max Output Voltage 530V
Turn On Delay Time 20 ms
Throw Configuration 3PST
Voltage - Input 90V~140VAC
Circuit 3PST-NO (3 Form A)
Output Type AC
Termination Style Screw Terminal
Depth 35.4mm
Min Operating Temperature -40°C
Max Operating Temperature 80°C
Termination Screw
Part Status Active
Series 53TP
Packaging Tube

Physical

Number of Pins 8
Package / Case Module
Mounting Type Chassis Mount
Mount Chassis Mount, Panel, Screw

Supply Chain

Factory Lead Time 6 Weeks
