AQZ205D image
Favorite
AQZ205D image
Favorite
RoHS
RoHS RoHS compliant
Package 4-SIP
Category Relays / Solid State Relays
Description RELAY OPTO AC/DC 100V 1.8A 4-SIP
PDF
/
Buying Options
Total Price: USD $9.57
Unit Price: USD $9.5744
≥1 USD $9.5744
≥10 USD $8.97952
≥100 USD $7.981248
≥500 USD $7.582432
≥1000 USD $7.183264
≥3000 USD $6.385139
Inventory: 546
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 4-SIP
Number of Pins 4

Technical

Packaging Tube
Published 2004
Series PhotoMOS? AQZ
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Resistance 340mOhm
Additional Feature HIGH SENSITIVITY
Termination Style PC Pin
Approval Agency cULus
Operating Temperature (Max) 85°C
Operating Temperature (Min) -20°C
Output Voltage 100V
Output Type AC, DC
Max Output Current 1.8A
Number of Elements 1
Circuit SPST-NO (1 Form A)
Voltage - Input 1.4VDC
Throw Configuration SPST
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Max Output Voltage 100V
Relay Type Relay
Voltage - Load 0V~100V
On-State Resistance (Max) 340mOhm
Isolation Voltage 2.5kV

Dimensions

Height 12.5mm
Length 21mm
Width 3.5mm

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
