AQY414EHA
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
SSR RELAY SPST-NC 120MA 0-400V
PDF
/
Buying Options
Total Price: USD $1.8
Unit Price: USD $1.7974
≥1 USD $1.7974
≥10 USD $1.47535
≥100 USD $1.4288
≥500 USD $1.3832
≥1000 USD $1.33665
Inventory: 19046
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.78mm
Length 6.4mm
Height 2.9mm
Technical
Test Voltage 5kV
Isolation Voltage 5kV
On-State Current-Max 0.12A
Input Current 50mA
Max Input Current 50mA
On-State Resistance (Max) 35Ohm
Voltage - Load 0V~400V
Relay Type Relay
Max Output Voltage 400V
Forward Current 1.4mA
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Throw Configuration SPST
Output Current 120mA
Voltage - Input 1.14VDC
Contact Resistance 26Ohm
Circuit SPST-NC (1 Form B)
Number of Elements 1
Max Output Current 120mA
Output Type AC, DC
Output Voltage 400V
Voltage - Rated AC 400V
Termination Style Gull Wing
Current Rating 120mA
Additional Feature HIGH SENSITIVITY, UL RECOGNIZED
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 35Ohm
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series PhotoMOS? AQY
Published 2000
Packaging Tube
Physical
Number of Pins 4
Package / Case 4-SMD (0.300, 7.62mm)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
