AQY282SX
RoHS
RoHS compliant
RoHS compliantPackage 4-SOP (0.173, 4.40mm)
Category Relays / Solid State Relays
Description
SSR RELAY SPST-NO 500MA 0-60V
PDF
/
Buying Options
Total Price: USD $1.26
Unit Price: USD $1.26248
≥1 USD $1.26248
≥10 USD $1.19102
≥100 USD $1.1236
≥500 USD $1.06
≥1000 USD $1
≥3000 USD $0.9434
Inventory: 43022
Minimum: 1
-
+
Technical Details
Technical
Input Current 1.8mA
On-State Current-Max 0.5A
Isolation Voltage 1.5kV
Ambient Temperature Range High 85°C
On-State Resistance 2.5Ohm
Packaging Tape & Reel (TR)
Published 2003
Series PhotoMOS? AQY
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination Gull Wing
Resistance 2.5Ohm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature HIGH SENSITIVITY
Capacitance 800FF
Max Power Dissipation 350mW
Termination Style Gull Wing
Output Voltage 60V
Output Type AC, DC
Max Output Current 500mA
Number of Elements 1
Circuit SPST-NO (1 Form A)
Voltage - Input 1.14VDC
Output Current 500mA
Throw Configuration SPST
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Forward Current 1.8mA
Max Output Voltage 60V
Max Input Voltage 1.5V
Relay Type Relay
Voltage - Load 0V~60V
On-State Resistance (Max) 2.5Ohm
Max Input Current 50mA
Dimensions
Height 2.3mm
Length 4.4mm
Width 4.3mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-SOP (0.173, 4.40mm)
Number of Pins 4
