AQY216EHAZ
RoHS
/
Package 4-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
Solid state relay 600 VAC/DC 50 mA, AQY216EHAZ
PDF
/
Buying Options
Total Price: USD $5.02
Unit Price: USD $5.02455
≥1 USD $5.02455
≥10 USD $4.123
≥100 USD $3.9938
≥500 USD $3.86555
≥1000 USD $3.73635
Inventory: 1932
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mounting Type Surface Mount
Package / Case 4-SMD (0.300, 7.62mm)
Technical
Packaging Tape & Reel (TR)
Series PhotoMOS? AQY
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Terminal Finish Matte Tin (Sn)
Additional Feature HIGH SENSITIVITY, UL RECOGNIZED
HTS Code 8541.40.95.00
Subcategory Solid State Relays
Termination Style Gull Wing
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Output Type AC, DC
Number of Elements 1
Circuit SPST-NO (1 Form A)
Configuration SINGLE
Voltage - Input 1.14VDC
Input Type DC
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Voltage - Load 0V~600V
Forward Current-Max 0.05A
On-State Resistance (Max) 120Ohm
Overall Height 2.9mm
On-State Current-Max 0.05A
Load Current 50mA
Isolation Voltage-Max 5000V
Overall Length 4.78mm
Compliance
RoHS Status RoHS Compliant
