AQY212EHA
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
SSR RELAY SPST-NO 550MA 0-60V
PDF
/
Buying Options
Total Price: USD $1.54
Unit Price: USD $1.54
≥1 USD $1.54
≥10 USD $1.43968
≥100 USD $1.279872
≥500 USD $1.215808
≥1000 USD $1.151832
≥3000 USD $1.02388
Inventory: 434
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 4.78mm
Length 6.4mm
Height 2.9mm
Technical
Test Voltage 5kV
Isolation Voltage 5kV
On-State Current-Max 0.55A
Input Current 50mA
Max Input Current 50mA
On-State Resistance (Max) 2.5Ohm
Voltage - Load 0V~60V
Relay Type Relay
Max Output Voltage 60V
Forward Current 1.2mA
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Input Type DC
Throw Configuration SPST
Output Current 550mA
Voltage - Input 1.14VDC
Contact Resistance 850mOhm
Circuit SPST-NO (1 Form A)
Number of Elements 1
Max Output Current 550mA
Output Type AC, DC
Output Voltage 60V
Termination Style Gull Wing
Current Rating 550mA
Max Power Dissipation 550mW
Additional Feature HIGH SENSITIVITY, UL RECOGNIZED
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
Resistance 2.5Ohm
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PhotoMOS? AQY
Published 2000
Packaging Tube
Physical
Number of Pins 4
Package / Case 4-SMD (0.300, 7.62mm)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
