AQW212EHAZ
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
Relay SSR 50mA 1.5V DC-IN 0.5A 60V AC/DC-OUT 8-Pin PDIP SMD T/R
PDF
/
Buying Options
Total Price: USD $2.73
Unit Price: USD $2.728
≥1 USD $2.728
≥10 USD $2.55992
≥100 USD $2.275328
≥500 USD $2.161632
≥1000 USD $2.04776
≥3000 USD $1.820262
Inventory: 163
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SMD (0.300, 7.62mm)
Number of Pins 8
Technical
Packaging Tape & Reel (TR)
Published 2000
Series PhotoMOS? AQW
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
Termination Style Gull Wing
Operating Temperature (Min) -40°C
Output Type AC, DC
Max Output Current 500mA
Number of Elements 2
Circuit SPST-NO (1 Form A) x 2
Voltage - Input 1.14VDC
Throw Configuration DPST
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Max Output Voltage 60V
Max Input Voltage 1.5V
Voltage - Load 0V~60V
Forward Current-Max 0.05A
On-State Resistance (Max) 2.5Ohm
Max Input Current 50mA
Input Current 50mA
On-State Current-Max 0.6A
Isolation Voltage-Max 5000V
Dimensions
Height 2.9mm
Length 9.86mm
Width 6.4mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
