AQW210SZ
RoHS
RoHS compliant
RoHS compliantPackage 8-SOP (0.173, 4.40mm Width)
Category Relays / Solid State Relays
Description
PANASONIC ELECTRIC WORKS AQW210SZ PHOTOMOS RELAY, 350V, 100mA
PDF
/
Buying Options
Total Price: USD $3.94
Unit Price: USD $3.9424
≥1 USD $3.9424
≥10 USD $3.69424
≥100 USD $3.283456
≥500 USD $3.119424
≥1000 USD $2.955128
≥3000 USD $2.6268
Inventory: 14664
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOP (0.173, 4.40mm Width)
Number of Pins 8
Technical
Packaging Tape & Reel (TR)
Published 2004
Series PhotoMOS? AQW
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination Gull Wing
Resistance 35Ohm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature LOW LEAKAGE CURRENT, UL APPROVED
Max Power Dissipation 650mW
Termination Style Gull Wing
Output Voltage 350V
Output Type AC, DC
Max Output Current 100mA
Number of Elements 2
Circuit SPST-NO (1 Form A) x 2
Voltage - Input 1.14VDC
Output Current 100mA
Throw Configuration DPST
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Forward Current 900μA
Max Output Voltage 350V
Max Input Voltage 1.5V
Rise Time 230μs
Relay Type Relay
Voltage - Load 0V~350V
On-State Resistance (Max) 35Ohm
Max Input Current 50mA
Input Current 50mA
On-State Current-Max 0.1A
Isolation Voltage 1.5kV
Dimensions
Height 2.1mm
Length 9.37mm
Width 4.4mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
