AQV453AZ image
Favorite
AQV453AZ image
Favorite
RoHS
RoHS RoHS compliant
Package 6-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description RELAY OPTO AC/DC 250V 200MA 6SMD
PDF
/
Buying Options
Total Price: USD $19.19
Unit Price: USD $19.18525
≥1 USD $19.18525
≥10 USD $15.7415
≥100 USD $15.25035
≥500 USD $14.75825
≥1000 USD $14.26615
Inventory: 5303
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 6.4mm
Length 8.8mm
Height 3.6mm

Technical

Test Voltage 1.5kV
Isolation Voltage 1.5kV
On-State Current-Max 0.2A
Input Current 50mA
Max Input Current 50mA
On-State Resistance (Max) 8Ohm
Forward Current-Max 0.05A
Voltage - Load 0V~250V
Relay Type Relay
Max Output Voltage 250V
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Throw Configuration SPST
Output Current 200mA
Voltage - Input 1.14VDC
Circuit SPST-NC (1 Form B)
Number of Elements 1
Max Output Current 200mA
Output Type AC, DC
Output Voltage 250V
Termination Style Gull Wing
HTS Code 8541.40.95.00
Additional Feature HIGH SENSITIVITY
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 8Ohm
Termination Gull Wing
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series PhotoMOS? AQV
Published 2005
Packaging Tape & Reel (TR)

Physical

Number of Pins 6
Package / Case 6-SMD (0.300, 7.62mm)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
