AQV414S
RoHS
RoHS compliant
RoHS compliantPackage 6-SOP (0.173, 4.40mm)
Category Relays / Solid State Relays
Description
RELAY OPTO AC/DC 400V 100MA 6SOP
PDF
/
Buying Options
Total Price: USD $3.95
Unit Price: USD $3.9512
≥1 USD $3.9512
≥10 USD $3.70392
≥100 USD $3.292256
≥500 USD $3.12752
≥1000 USD $2.96296
≥3000 USD $2.633726
Inventory: 1176
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.4mm
Length 6.3mm
Height 2.1mm
Technical
Test Voltage 1.5kV
Isolation Voltage 1.5kV
On-State Current-Max 0.1A
Input Current 50mA
Max Input Current 50mA
On-State Resistance (Max) 50Ohm
Voltage - Load 0V~400V
Relay Type Relay
Rise Time 470 μs
Max Output Voltage 400V
Forward Current 550μA
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Throw Configuration SPST
Output Current 100mA
Voltage - Input 1.14VDC
Contact Resistance 26Ohm
Circuit SPST-NC (1 Form B)
Number of Elements 1
Max Output Current 100mA
Output Type AC, DC
Output Voltage 400V
Approval Agency cULus
Termination Style Gull Wing
HTS Code 8541.40.95.00
Additional Feature UL RECOGNIZED
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 50Ohm
Termination Gull Wing
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series PhotoMOS? AQV
Published 2000
Packaging Tube
Physical
Number of Pins 6
Package / Case 6-SOP (0.173, 4.40mm)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
