AQV258AX image
Favorite
AQV258AX image
Favorite
RoHS
RoHS RoHS compliant
Package 6-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description SSR RELAY SPST-NO 20MA 0-1500V
PDF
/
Buying Options
Total Price: USD $3.94
Unit Price: USD $3.9444
≥1 USD $3.9444
≥10 USD $3.23665
≥100 USD $3.135
≥500 USD $3.0343
≥1000 USD $2.9336
Inventory: 34128
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Width 6.4mm
Length 8.8mm
Height 3.6mm

Technical

Test Voltage 1.5kV
Load Current 20mA
Input Current 50mA
Max Input Current 50mA
On-State Resistance (Max) 500Ohms
Voltage - Load 0V~1500V
Relay Type Relay
Rise Time 350μs
Max Output Voltage 1.5kV
Throw Configuration SPST
Output Current 20mA
Voltage - Input 1.14VDC
Circuit SPST-NO (1 Form A)
Max Output Current 20mA
Output Type AC, DC
Output Voltage 100V
Termination Style Gull Wing
Resistance 500Ohm
Termination Gull Wing
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series PhotoMOS? AQV
Published 2000
Packaging Tape & Reel (TR)

Physical

Supplier Device Package 6-SMD
Number of Pins 6
Package / Case 6-SMD (0.300, 7.62mm)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
