AQV225NSX
RoHS
/
Package 6-SOP (0.173, 4.40mm)
Category Relays / Solid State Relays
Description
RELAY OPTO AC/DC 80V 120MA 6-SOP
PDF
/
Buying Options
Total Price: USD $1.11
Unit Price: USD $1.10675
≥1 USD $1.10675
≥10 USD $0.9082
≥100 USD $0.8797
≥500 USD $0.8512
≥1000 USD $0.8227
Inventory: 1255
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SOP (0.173, 4.40mm)
Number of Pins 6
Technical
Packaging Tape & Reel (TR)
Published 2001
Series PhotoMOS? AQV
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination Gull Wing
Resistance 10Ohm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature RADIO FREQUENCY TYPE, UL RECOGNIZED
HTS Code 8541.40.95.00
Termination Style Gull Wing
Output Type AC, DC (RF)
Max Output Current 120mA
Number of Elements 1
Circuit SPST-NO (1 Form A)
Voltage - Input 1.14VDC
Output Current 120mA
Throw Configuration SPST
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Max Output Voltage 80V
Relay Type Relay
Voltage - Load 0V~80V
Forward Current-Max 0.05A
On-State Resistance (Max) 10Ohm
Max Input Current 50mA
Input Current 50mA
On-State Current-Max 0.12A
Isolation Voltage 1.5kV
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
