AQV214EA image
Favorite
AQV214EA image
Favorite
RoHS
RoHS RoHS compliant
Package 6-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description SSR RELAY SPST-NO 120MA 0-400V
PDF
/
Buying Options
Total Price: USD $2.2
Unit Price: USD $2.2021
≥1 USD $2.2021
≥10 USD $1.8069
≥100 USD $1.75085
≥500 USD $1.69385
≥1000 USD $1.6378
Inventory: 1252
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD (0.300, 7.62mm)
Number of Pins 6

Technical

Packaging Tube
Published 2000
Series PhotoMOS? AQV
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
Resistance 50Ohm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature UL RECOGNIZED
HTS Code 8541.40.95.00
Termination Style Gull Wing
Output Voltage 400V
Output Type AC, DC
Max Output Current 120mA
Number of Elements 1
Circuit SPST-NO (1 Form A)
Contact Resistance 30Ohm
Voltage - Input 1.14VDC
Output Current 120mA
Throw Configuration SPST
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Max Output Voltage 400V
Rise Time 500μs
Relay Type Relay
Voltage - Load 0V~400V
Forward Current-Max 0.05A
On-State Resistance (Max) 50Ohm
Max Input Current 50mA
Input Current 50mA
On-State Current-Max 0.12A
Isolation Voltage 1.5kV
Test Voltage 1.5kV

Dimensions

Height 3.6mm
Length 8.8mm
Width 6.4mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
