AQV214AX
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
RELAY OPTO AC/DC 400V 120MA 6SMD
PDF
/
Buying Options
Total Price: USD $1.66
Unit Price: USD $1.65965
≥1 USD $1.65965
≥10 USD $1.36135
≥100 USD $1.31955
≥500 USD $1.2768
≥1000 USD $1.23405
Inventory: 1096
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 6.4mm
Length 8.8mm
Height 3.6mm
Technical
Test Voltage 1.5kV
Isolation Voltage-Max 1500V
On-State Current-Max 0.12A
Input Current 50mA
Max Input Current 50mA
On-State Resistance (Max) 50Ohm
Forward Current-Max 0.05A
Voltage - Load 0V~400V
Relay Type Relay
Max Output Voltage 400V
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Throw Configuration SPST
Voltage - Input 1.14VDC
Circuit SPST-NO (1 Form A)
Number of Elements 1
Max Output Current 120mA
Output Type AC, DC
Output Voltage 400V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Termination Style Gull Wing
HTS Code 8541.40.95.00
Additional Feature UL RECOGNIZED
Resistance 50Ohm
Termination Gull Wing
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Series PhotoMOS? AQV
Published 2004
Packaging Tape & Reel (TR)
Physical
Number of Pins 6
Package / Case 6-SMD (0.300, 7.62mm)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
