AQV210
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
PANASONIC EW AQV210 PHOTOMOS RELAY, 350V, 130mA
PDF
/
Buying Options
Total Price: USD $2.83
Unit Price: USD $2.83005
≥1 USD $2.83005
≥10 USD $2.3218
≥100 USD $2.2496
≥500 USD $2.1774
≥1000 USD $2.10425
Inventory: 15518
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Width 6.4mm
Length 8.8mm
Height 3.9mm
Technical
Test Voltage 1.5kV
Isolation Voltage 1.5kV
Load Current 130mA
On-State Current-Max 0.13A
Input Current 50mA
Max Input Current 50mA
On-State Resistance (Max) 35Ohm
Voltage - Load 0V~350V
Relay Type Relay
Max Output Voltage 350V
Forward Current 1mA
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Throw Configuration SPST
Voltage - Input 1.14VDC
Contact Resistance 23Ohm
Circuit SPST-NO (1 Form A)
Number of Elements 1
Max Output Current 170mA
Output Type AC, DC
Output Voltage 350V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Termination Style PC Pin
HTS Code 8541.40.95.00
Additional Feature UL RECOGNIZED
Resistance 35Ohm
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series PhotoMOS? AQV
Published 2004
Packaging Tube
Physical
Number of Pins 6
Package / Case 6-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
