AQ2A2-C1-T5VDC
RoHS
RoHS compliant
RoHS compliantPackage 4-SIP
Category Relays / Solid State Relays
Description
PANASONIC ELECTRIC WORKS AQ2A2-C1-T5VDC SSR, PCB MOUNT, 250VAC, 6VDC, 2A
PDF
/
Buying Options
Total Price: USD $7.26
Unit Price: USD $7.26
≥1 USD $7.26
≥10 USD $6.80504
≥100 USD $5.7464
≥500 USD $5.443856
≥1000 USD $5.324607
Inventory: 991
Minimum: 1
-
+
Technical Details
Technical
Max Output Current 2A
Circuit SPST-NO (1 Form A)
Max Voltage Rating (AC) 250V
Voltage - Input 4V~6VDC
Output Current 2A
Throw Configuration SPST
Max Output Voltage 250V
Relay Type Relay
Voltage - Load 75V~250V
Isolation Voltage 3kV
Max Supply Voltage (AC) 250V
Min Supply Voltage (AC) 75V
Output Type AC
Output Voltage 250V
Termination Style PC Pin
Min Operating Temperature -30°C
Max Operating Temperature 80°C
Termination PC Pin
Part Status Active
Series AQ8
Published 2000
Packaging Bulk
Dimensions
Height 24mm
Length 45mm
Width 9mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Number of Pins 4
Package / Case 4-SIP
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
