G3VM-WL image
Favorite
RoHS
RoHS RoHS compliant
Package 8-DIP (0.300, 7.62mm)
Category Relays / Solid State Relays
Description SSR RELAY SPST-NO 120MA 0-350V
PDF
/
Buying Options
Total Price: USD $3.66
Unit Price: USD $3.65845
≥1 USD $3.65845
≥10 USD $3.002
≥100 USD $2.90795
≥500 USD $2.81485
≥1000 USD $2.7208
Inventory: 32007
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Width 6.4mm
Length 9.66mm
Height 3.65mm

Technical

Isolation Voltage-Max 2500V
On-State Current-Max 0.1A
Max Input Current 50mA
On-State Resistance (Max) 35Ohm
Forward Current-Max 0.025A
Voltage - Load 0V~350V
Relay Type Relay
Max Input Voltage 1.3V
Max Output Voltage 350V
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Throw Configuration DPST
Voltage - Input 1.15VDC
Circuit SPST-NO (1 Form A) x 2
Number of Elements 2
Max Output Current 120mA
Output Type AC, DC
Operating Temperature (Min) -20°C
Operating Temperature (Max) 65°C
Termination Style PC Pin
Reach Compliance Code unknown
Additional Feature UL RECOGNIZED
Resistance 35Ohm
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series G3VM
Published 2001
Packaging Tube

Physical

Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 15 Weeks
