G3VM-41LR5
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD (0.165, 4.20mm)
Category Relays / Solid State Relays
Description
OMRON ELECTRONIC COMPONENTS G3VM-41LR5 MOSFET Relay, 40 VAC, 300 mA, 1.5 ohm, SPST-NO
PDF
/
Buying Options
Total Price: USD $13.77
Unit Price: USD $13.767069
≥1 USD $13.767069
≥200 USD $5.493174
≥500 USD $5.310681
≥1000 USD $5.218778
Inventory: 1404
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount PCB, Surface Mount
Mounting Type Surface Mount
Package / Case 4-SMD (0.165, 4.20mm)
Number of Pins 4
Technical
Packaging Tube
Published 2001
Series G3VM
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination SMD/SMT
Resistance 1.5Ohm
Max Operating Temperature 85°C
Min Operating Temperature -20°C
Additional Feature UL RECOGNIZED
Depth 3.5mm
Termination Style SMD (SMT) Tab
Output Voltage 40V
Output Type AC, DC
Max Output Current 300mA
Number of Elements 1
Circuit SPST-NO (1 Form A)
Voltage - Input 1.15VDC
Output Current 300mA
Throw Configuration SPST
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Forward Current 30mA
Max Output Voltage 40V
Max Input Voltage 1.3V
Relay Type Relay
Voltage - Load 0V~40V
On-State Resistance (Max) 1.5Ohm
Max Input Current 50mA
Input Current 50mA
On-State Current-Max 0.3A
Isolation Voltage 1.5kV
Dimensions
Height 1.8mm
Length 2.04mm
Width 2mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
