G3VM-401EY image
Favorite
G3VM-401EY image
Favorite
RoHS
RoHS RoHS compliant
Package 6-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description OMRON - G3VM-401EY - MOSFET Relay, 400 VAC, 120 mA, 35 ohm, SPST-NO
PDF
/
Buying Options
Total Price: USD $3.04
Unit Price: USD $3.0448
≥1 USD $3.0448
≥10 USD $2.85648
≥100 USD $2.539328
≥500 USD $2.412432
≥1000 USD $2.285536
≥3000 USD $2.031568
Inventory: 480
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No

Dimensions

Width 6.4mm
Length 7.12mm
Height 3.65mm

Technical

Isolation Voltage 5kV
On-State Current-Max 0.12A
Input Current 50mA
Max Input Current 50mA
On-State Resistance (Max) 35Ohm
Voltage - Load 0V~400V
Relay Type Relay
Max Input Voltage 1.3V
Max Output Voltage 400V
Forward Current 7.5mA
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Throw Configuration SPST
Output Current 120mA
Voltage - Input 1.15VDC
Contact Resistance 10Ohm
Circuit SPST-NO (1 Form A)
Number of Elements 1
Max Output Current 120mA
Output Type AC, DC
Output Voltage 400V
Approval Agency UL
Voltage - Rated AC 400V
Termination Style Gull Wing
Current Rating 120mA
Depth 6.4mm
Capacitance 800FF
HTS Code 8541.40.95.00
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 35Ohm
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series G3VM
Published 2001
Packaging Tube

Physical

Number of Pins 6
Package / Case 6-SMD (0.300, 7.62mm)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 7 Weeks
