G3VM-401A
RoHS
RoHS compliant
RoHS compliantPackage 4-DIP (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
OMRON ELECTRONIC COMPONENTS G3VM-401A MOSFET Relay, 400 VAC, 120 mA, 35 ohm, SPST-NO
PDF
/
Buying Options
Total Price: USD $2.82
Unit Price: USD $2.8248
≥1 USD $2.8248
≥10 USD $2.65056
≥100 USD $2.355936
≥500 USD $2.238192
≥1000 USD $2.120448
≥3000 USD $1.88481
Inventory: 5103
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 4-DIP (0.300, 7.62mm)
Number of Pins 4
Technical
Packaging Tube
Published 2001
Series G3VM
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Resistance 35Ohm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Capacitance 800FF
Depth 6.4mm
Current Rating 120mA
Termination Style PC Pin
Voltage - Rated AC 400V
Approval Agency UL
Output Voltage 400V
Output Type AC, DC
Max Output Current 120mA
Number of Elements 1
Circuit SPST-NO (1 Form A)
Contact Resistance 18Ohm
Insulation Resistance 1GOhm
Voltage - Input 1.15VDC
Output Current 120mA
Throw Configuration SPST
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Forward Current 7.5mA
Max Output Voltage 400V
Max Input Voltage 1.3V
Relay Type Relay
Voltage - Load 0V~400V
On-State Resistance (Max) 35Ohm
Max Input Current 50mA
Input Current 50mA
On-State Current-Max 0.1A
Isolation Voltage 2.5kV
Dimensions
Height 3.65mm
Length 4.58mm
Width 4.6mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
