G3VM-21PR10
RoHS
/
Package 4-SMD (0.128, 3.25mm)
Category Relays / Solid State Relays
Description
SSR RELAY SPST-NO 200MA 0-20V
PDF
/
Buying Options
Total Price: USD $76.53
Unit Price: USD $76.52535
≥1 USD $76.52535
≥10 USD $74.1342
≥100 USD $71.7421
≥500 USD $69.35095
≥1000 USD $62.17655
Inventory: 1159
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 2.2mm
Length 2.85mm
Height 1.85mm
Technical
On-State Resistance 3Ohm
Ambient Temperature Range High 65°C
Max Junction Temperature (Tj) 125°C
Isolation Voltage 500V
Input Current 7.5mA
Max Input Current 20mA
On-State Resistance (Max) 5Ohm
Voltage - Load 0V~20V
Relay Type Relay
Max Input Voltage 1.3V
Max Output Voltage 16V
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Throw Configuration SPST
Output Current 200mA
Voltage - Input 1.15VDC
Circuit SPST-NO (1 Form A)
Max Output Current 200mA
Output Type AC, DC
Output Voltage 16V
Termination Style SMD (SMT) Tab
Capacitance 800FF
Min Operating Temperature -20°C
Max Operating Temperature 125°C
Resistance 5Ohm
Termination Solder
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series G3VM
Published 2001
Packaging Bulk
Physical
Weight 249.986095mg
Number of Pins 4
Package / Case 4-SMD (0.128, 3.25mm)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
