G3VM-21LR10 image
Favorite
G3VM-21LR10 image
Favorite
RoHS
/
Package 4-SMD (0.165, 4.20mm)
Category Relays / Solid State Relays
Description OMRON - G3VM-21LR10 - RELAY, MOSFET, SPST-NO, 20V, 0.2A
PDF
/
Buying Options
Total Price: USD $8.92
Unit Price: USD $8.91765
≥1 USD $8.91765
≥10 USD $7.31785
≥100 USD $7.0889
≥500 USD $6.85995
≥1000 USD $6.63195
Inventory: 8403
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No

Dimensions

Length 1.9mm
Height 1.8mm

Technical

Isolation Voltage 1.5kV
On-State Current-Max 0.2A
Input Current 30mA
Max Input Current 30mA
On-State Resistance (Max) 5Ohm
Voltage - Load 0V~20V
Relay Type Relay
Max Input Voltage 1.45V
Max Output Voltage 20V
Forward Current 20mA
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Throw Configuration SPST
Output Current 200mA
Voltage - Input 1.15VDC
Circuit SPST-NO (1 Form A)
Number of Elements 1
Max Output Current 200mA
Output Type AC, DC
Termination Style SMD (SMT) Tab
Depth 3.65mm
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Resistance 5Ohm
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
Series G3VM
Published 2001
Packaging Bulk

Physical

Number of Pins 4
Package / Case 4-SMD (0.165, 4.20mm)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 21 Weeks
