RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
SSR RELAY SPDT 170MA 0-250V
PDF
/
Buying Options
Total Price: USD $5.52
Unit Price: USD $5.5176
≥1 USD $5.5176
≥10 USD $5.17088
≥100 USD $4.596064
≥500 USD $4.366208
≥1000 USD $4.136352
≥3000 USD $3.676781
Inventory: 1139
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 6.35mm
Length 9.65mm
Height 3.3mm
Technical
Isolation Voltage 3.75kV
Load Current 170mA
Input Current 50mA
Max Input Current 50mA
On-State Resistance (Max) 20Ohms
Voltage - Load 0V~250V
Relay Type Relay
Max Output Voltage 250V
Forward Current 10mA
Throw Configuration SPDT
Output Current 170mA
Voltage - Input 1.2VDC
Circuit SPDT (1 Form C)
Max Output Current 170mA
Output Type AC, DC
Output Voltage 250V
Termination Style PC Pin
Max Power Dissipation 800mW
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 20Ohm
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series LCC, OptoMOS?
Published 2011
Packaging Tube
Physical
Supplier Device Package 8-DIP
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 6 Weeks
