LBB126STR
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
RELAY OPTOMOS 170MA DP-NC 8-SMD
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
Inventory: 855
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SMD (0.300, 7.62mm)
Number of Pins 8
Supplier Device Package 8-SMD
Technical
Packaging Tape & Reel (TR)
Published 2001
Series LBB, OptoMOS?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
Resistance 15Ohm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Max Power Dissipation 800mW
Termination Style Gull Wing
Output Voltage 250V
Output Type AC, DC
Circuit SPST-NC (1 Form B) x 2
Voltage - Input 1.2VDC
Output Current 170mA
Throw Configuration DPST
Max Output Voltage 250V
Relay Type Relay
Voltage - Load 0V~250V
On-State Resistance (Max) 15Ohms
Input Current 50mA
Load Current 170mA
Isolation Voltage 3.75kV
Dimensions
Height 3.302mm
Length 9.652mm
Width 6.35mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
