LBA120P image
Favorite
RoHS
RoHS RoHS compliant
Package 8-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description Lead Free AC DC ROHS3Compliant Active Solid State Relay 800mW 1.2VDC 2.159mm 50mA
PDF
/
Buying Options
Total Price: USD $3.81
Unit Price: USD $3.813975
≥1 USD $3.813975
≥200 USD $1.477013
≥500 USD $1.424497
≥1000 USD $1.399551
Inventory: 1475
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Width 6.35mm
Length 9.652mm
Height 2.159mm

Technical

Load Current 170mA
Input Current 50mA
On-State Resistance (Max) 20Ohms
Voltage - Load 0V~250V
Relay Type Relay
Throw Configuration DPST, SPST
Voltage - Input 1.2VDC
Circuit SPST-NO + SPST-NC (1 Form A and B)
Output Type AC, DC
Termination Style Gull Wing
Max Power Dissipation 800mW
Resistance 20Ohm
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series LBA, OptoMOS?
Published 2012
Packaging Tube

Physical

Supplier Device Package 8-Flatpack
Number of Pins 8
Package / Case 8-SMD (0.300, 7.62mm)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 8 Weeks
