LBA120L image
Favorite
RoHS
RoHS RoHS compliant
Package 8-DIP (0.300, 7.62mm)
Category Relays / Solid State Relays
Description RELAY SPST-NO/NC 150MA 0-250V
PDF
/
Buying Options
Total Price: USD $3.08
Unit Price: USD $3.078751
≥1 USD $3.078751
≥200 USD $1.192113
≥500 USD $1.1501
≥1000 USD $1.129094
Inventory: 5844
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Number of Pins 8
Supplier Device Package 8-DIP

Technical

Packaging Tube
Published 2010
Series LBA, OptoMOS?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Resistance 25Ohm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Max Power Dissipation 800mW
Termination Style PC Pin
Output Type AC, DC
Max Output Current 150mA
Circuit SPST-NO + SPST-NC (1 Form A and B)
Voltage - Input 1.2VDC
Output Current 150mA
Throw Configuration DPST, SPST
Max Output Voltage 250V
Relay Type Relay
Voltage - Load 0V~250V
On-State Resistance (Max) 25Ohms
Max Input Current 50mA
Input Current 50mA
Load Current 150mA
Isolation Voltage 3.75kV

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
