LBA110LS
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
RELAY SPST-NO/NC 120MA 0-350V
PDF
/
Buying Options
Total Price: USD $6.64
Unit Price: USD $6.63955
≥1 USD $6.63955
≥10 USD $5.44825
≥100 USD $5.2782
≥500 USD $5.10815
≥1000 USD $4.93715
Inventory: 55
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 6.35mm
Length 9.652mm
Height 3.302mm
Technical
Isolation Voltage 3.75kV
Load Current 120mA
Input Current 50mA
Max Input Current 50mA
On-State Resistance (Max) 35Ohms
Voltage - Load 0V~350V
Relay Type Relay
Max Input Voltage 1.4V
Max Output Voltage 350V
Throw Configuration DPST, SPST
Output Current 120mA
Voltage - Input 1.2VDC
Circuit SPST-NO + SPST-NC (1 Form A and B)
Output Type AC, DC
Output Voltage 350V
Termination Style Gull Wing
Max Power Dissipation 800mW
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 35Ohm
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series LBA, OptoMOS?
Published 2012
Packaging Tube
Physical
Supplier Device Package 8-SMD
Number of Pins 8
Package / Case 8-SMD (0.300, 7.62mm)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
