RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
RELAY SPST-NO/NC 120MA 0-350V
PDF
/
Buying Options
Total Price: USD $2.75
Unit Price: USD $2.7456
≥1 USD $2.7456
≥10 USD $2.57752
≥100 USD $2.29152
≥500 USD $2.176944
≥1000 USD $2.062368
≥3000 USD $2.017171
Inventory: 105
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Number of Pins 8
Supplier Device Package 8-DIP
Technical
Packaging Tube
Published 2012
Series LBA, OptoMOS?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Resistance 35Ohm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Max Power Dissipation 800mW
Termination Style PC Pin
Output Type AC, DC
Circuit SPST-NO + SPST-NC (1 Form A and B)
Voltage - Input 1.2VDC
Output Current 120mA
Throw Configuration DPST, SPST
Max Output Voltage 350V
Relay Type Relay
Voltage - Load 0V~350V
On-State Resistance (Max) 35Ohms
Input Current 50mA
Load Current 120mA
Isolation Voltage 3.75kV
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
