LBA110 image
Favorite
RoHS
RoHS RoHS compliant
Package 8-DIP (0.300, 7.62mm)
Category Relays / Solid State Relays
Description RELAY SPST-NO/NC 120MA 0-350V
PDF
/
Buying Options
Total Price: USD $1.38
Unit Price: USD $1.3832
≥1 USD $1.3832
≥10 USD $1.13525
≥100 USD $1.09915
≥500 USD $1.064
≥1000 USD $1.02885
≥3000 USD $0.92245
Inventory: 22004
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Width 6.35mm
Length 9.65mm
Height 3.3mm

Technical

Isolation Voltage 3.75kV
Load Current 120mA
Input Current 50mA
Max Input Current 50mA
On-State Resistance (Max) 35Ohms
Voltage - Load 0V~350V
Relay Type Relay
Max Output Voltage 350V
Forward Current 5mA
Throw Configuration DPST, SPST
Output Current 120mA
Voltage - Input 1.2VDC
Circuit SPST-NO + SPST-NC (1 Form A and B)
Max Output Current 120mA
Output Type AC, DC
Output Voltage 350V
Termination Style PC Pin
Max Power Dissipation 800mW
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 35Ohm
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series LBA, OptoMOS?
Published 2011
Packaging Tube

Physical

Supplier Device Package 8-DIP
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 6 Weeks
