LAA120PL
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
SSR RELAY SPST-NO 150MA 0-250V
PDF
/
Buying Options
Total Price: USD $8.06
Unit Price: USD $8.05505
≥1 USD $8.05505
≥10 USD $6.60915
≥100 USD $6.403
≥500 USD $6.1959
≥1000 USD $5.98975
Inventory: 23
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 6.35mm
Length 9.652mm
Height 2.159mm
Technical
Isolation Voltage 3.75kV
Load Current 150mA
Input Current 50mA
On-State Resistance (Max) 25Ohms
Voltage - Load 0V~250V
Relay Type Relay
Max Output Voltage 250V
Throw Configuration DPST
Output Current 150mA
Voltage - Input 1.2VDC
Circuit SPST-NO (1 Form A) x 2
Output Type AC, DC
Termination Style Gull Wing
Max Power Dissipation 800mW
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 25Ohm
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series LAA, OptoMOS?
Published 2009
Packaging Tube
Physical
Supplier Device Package 8-Flatpack
Number of Pins 8
Package / Case 8-SMD (0.300, 7.62mm)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
