LAA100S image
Favorite
RoHS
RoHS RoHS compliant
Package 8-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description SSR RELAY SPST-NO 120MA 0-350V
PDF
/
Buying Options
Total Price: USD $8.11
Unit Price: USD $8.111096
≥1 USD $8.111096
≥200 USD $3.236299
≥500 USD $3.128641
≥1000 USD $3.074812
Inventory: 1364
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SMD (0.300, 7.62mm)
Number of Pins 8
Supplier Device Package 8-SMD

Technical

Packaging Tube
Published 2001
Series LAA, OptoMOS?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
Resistance 25Ohm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Max Power Dissipation 800mW
Termination Style Gull Wing
Output Type AC, DC
Circuit SPST-NO (1 Form A) x 2
Voltage - Input 1.2VDC
Output Current 120mA
Throw Configuration DPST
Max Output Voltage 350V
Relay Type Relay
Voltage - Load 0V~350V
On-State Resistance (Max) 25Ohms
Input Current 50mA
Load Current 120mA
Isolation Voltage 3.75kV

Dimensions

Height 3.302mm
Length 9.652mm
Width 6.35mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
