CPC1560GS image
Favorite
RoHS
RoHS RoHS compliant
Package 8-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description SSR RELAY SPST-NO 600MA 0-60V
PDF
/
Buying Options
Total Price: USD $3.17
Unit Price: USD $3.16882
≥1 USD $3.16882
≥10 USD $2.98945
≥100 USD $2.82024
≥500 USD $2.6606
≥1000 USD $2.51
≥3000 USD $2.36792
Inventory: 1314
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Technical

Isolation Voltage 3.75kV
Load Current 600mA
Input Current 50mA
On-State Resistance (Max) 5.6Ohms
Voltage - Load 0V~60V
Relay Type Relay
Max Output Voltage 60V
Throw Configuration SPST
Output Current 300mA
Voltage - Input 1.22VDC
Circuit SPST-NO (1 Form A)
Output Type AC, DC
Termination Style Gull Wing
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 5.6Ohm
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series CPC, OptoMOS?
Published 2008
Packaging Tube

Physical

Supplier Device Package 8-SMD
Number of Pins 8
Package / Case 8-SMD (0.300, 7.62mm)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 8 Weeks
