PVT322S-TPBF

Infineon Technologies
RoHS
RoHS RoHS compliant
Package 8-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description IC RELAY PHOTOVO 250V 170MA 8SMD
PDF
/
Buying Options
Total Price: USD $7.9
Unit Price: USD $7.9024
≥1 USD $7.9024
Inventory: 84
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Technical

Control Current 0.002A
Overall Length 9.4mm
Isolation Voltage 4kV
On-State Current-Max 0.17A
Input Current 25mA
Overall Height 3.42mm
Max Input Current 25mA
On-State Resistance (Max) 10Ohm
Forward Current-Max 0.025A
Voltage - Load 0V~250V
Relay Type Relay
Max Output Voltage 250V
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Input Type DC
Throw Configuration DP, DPST
Output Current 170mA
Voltage - Input 1.2VDC
Circuit SPST-NO (1 Form A) x 2
Number of Elements 2
Output Type AC, DC
Output Voltage 250V
Approval Agency UL
Termination Style Gull Wing
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
Resistance 10Ohm
Termination Gull Wing
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Active
JESD-609 Code e3
Series PVT, HEXFET?
Published 2009
Packaging Tape & Reel (TR)

Physical

Number of Pins 8
Package / Case 8-SMD (0.300, 7.62mm)
Mounting Type Surface Mount
Mount PCB, Surface Mount

Supply Chain

Factory Lead Time 16 Weeks
