PVN013S-T image
Favorite
PVN013S-T image
Favorite
RoHS
/
Package 6-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description IC RELAY PHOTOV 20V 2.5A 6SMD
PDF
/
Buying Options
Total Price: USD $6.08
Unit Price: USD $6.08285
≥1 USD $6.08285
≥10 USD $4.9913
≥100 USD $4.8355
≥500 USD $4.6797
≥1000 USD $4.5239
Inventory: 9102
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Technical

Control Current 0.003A
Overall Length 8.63mm
Isolation Voltage-Max 4000V
Load Current 2.5A
On-State Current-Max 2.5A
Overall Height 3.42mm
On-State Resistance (Max) 100mOhm
Forward Current-Max 0.025A
Voltage - Load 0V~20V
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Input Type DC
Voltage - Input 1.2VDC
Configuration SINGLE
Circuit SPST-NO (1 Form A)
Number of Elements 1
Output Type AC, DC
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Termination Style Gull Wing
Subcategory Solid State Relays
HTS Code 8541.40.95.00
Additional Feature UL RECOGNIZED
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Obsolete
Series PVN, HEXFET?
Published 2015
Packaging Tape & Reel (TR)

Physical

Package / Case 6-SMD (0.300, 7.62mm)
Mounting Type Surface Mount
