PVG613PBF
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
IC RELAY PHOTOVO 60V 1A 6-DIP
PDF
/
Buying Options
Total Price: USD $4.86
Unit Price: USD $4.8576
≥1 USD $4.8576
Inventory: 1438
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Control Current 0.005A
Isolation Voltage 4kV
On-State Current-Max 1A
Input Current 25mA
Overall Height 3.4mm
Max Input Current 25mA
On-State Resistance (Max) 500mOhm
Forward Current-Max 0.025A
Voltage - Load 0V~60V
Relay Type Relay
Max Output Voltage 60V
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Input Type AC/DC
Throw Configuration SP, SPST
Output Current 1A
Voltage - Input 1.2VDC
Circuit SPST-NO (1 Form A)
Number of Elements 1
Output Type AC, DC
Approval Agency UL
Termination Style PC Pin
HTS Code 8541.40.95.00
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 500mOhm
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Last Time Buy
Series PVG, HEXFET?
Published 2006
Packaging Tube
Physical
Number of Pins 6
Package / Case 6-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 15 Weeks
