PVA3054NS-TPBF
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD (0.300, 7.62mm), 4 Leads
Category Relays / Solid State Relays
Description
IC RELAY PHOTOVO 300V 50MA 8-SMD
PDF
/
Buying Options
Total Price: USD $8.77
Unit Price: USD $8.7736
≥1 USD $8.7736
≥10 USD $8.2236
≥100 USD $7.309632
≥500 USD $6.94408
≥1000 USD $6.578528
≥3000 USD $5.8476
Inventory: 1517
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Control Current 0.002A
Isolation Voltage 4kV
On-State Current-Max 0.05A
Input Current 25mA
Overall Height 3.9mm
Max Input Current 25mA
On-State Resistance (Max) 160Ohm
Forward Current-Max 0.025A
Voltage - Load 0V~300V
Relay Type Relay
Max Output Voltage 300V
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Input Type DC
Throw Configuration SPST
Voltage - Input 1.2VDC
Circuit SPST-NO (1 Form A)
Number of Elements 1
Output Type AC, DC
Approval Agency UL
Termination Style Gull Wing
Current Rating 50mA
Capacitance 2.2pF
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 160Ohm
Termination Gull Wing
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Active
Series PVA, HEXFET?
Published 2003
Packaging Tape & Reel (TR)
Physical
Number of Pins 4
Package / Case 8-SMD (0.300, 7.62mm), 4 Leads
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
