MCX380D5
RoHS
/
Package /
Category Relays / Solid State Relays
Description
TRIGGER OUTPUT SSR 8541.40.95.00 Tin (Sn) - with Nickel (Ni) barrier DC Solid State Relay 80C 4V 25.4mm 0.015A
PDF
/
Inventory: 9803
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Control Voltage 4V
Output Circuit Type Back to Back SCR
Control Current 0.015A
Overall Length 43.1mm
Isolation Voltage-Max 4000V
On-State Current-Max 5A
Overall Height 25.4mm
Forward Current-Max 0.015A
Optoelectronic Device Type TRIGGER OUTPUT SSR
Input Type DC
Number of Elements 1
Operating Temperature (Min) -40°C
Operating Temperature (Max) 80°C
Reach Compliance Code compliant
Subcategory Solid State Relays
HTS Code 8541.40.95.00
Additional Feature UL RECOGNIZED, ZERO VOLTAGE CROSSING
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Pbfree Code icon-pbfree yes
JESD-609 Code e3
