MCPC4890D
RoHS
/
Package /
Category Relays / Solid State Relays
Description
TRIGGER OUTPUT SSR 8541.40.95.00 DC RoHS Compliant Solid State Relay 80C 5V 22.9mm 28A
PDF
/
Buying Options
Total Price: USD $253.86
Unit Price: USD $253.857092
≥1 USD $253.857092
≥200 USD $98.239055
≥500 USD $94.787441
≥1000 USD $93.080671
Inventory: 8411
Minimum: 1
-
+
Technical Details
Technical
Pbfree Code icon-pbfree yes
Additional Feature UL RECOGNIZED
HTS Code 8541.40.95.00
Subcategory Solid State Relays
Reach Compliance Code compliant
Operating Temperature (Max) 80°C
Operating Temperature (Min) -20°C
Number of Elements 1
Configuration SINGLE WITH BUILT-IN SNUBBER
Input Type DC
Optoelectronic Device Type TRIGGER OUTPUT SSR
Forward Current-Max 0.00125A
Overall Height 22.9mm
On-State Current-Max 90A
Isolation Voltage-Max 4000V
Overall Length 58.4mm
Control Current 28A
Output Circuit Type SCR
Control Voltage 5V
Compliance
RoHS Status RoHS Compliant
