CWD2490
RoHS
/
Package /
Category Relays / Solid State Relays
Description
TRIGGER OUTPUT SSR 8541.40.95.00 Tin (Sn) AC Solid State Relay 80C 90V 33mm 0.006A
PDF
/
Buying Options
Total Price: USD $154.44
Unit Price: USD $154.43774
≥1 USD $154.43774
≥200 USD $59.765834
≥500 USD $57.665194
≥1000 USD $56.628003
Inventory: 6549
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Control Voltage 90V
Output Circuit Type SCR
Control Current 0.006A
Overall Length 58.4mm
Isolation Voltage-Max 4000V
On-State Current-Max 90A
Overall Height 33mm
Optoelectronic Device Type TRIGGER OUTPUT SSR
Input Type AC
Number of Elements 1
Operating Temperature (Min) -40°C
Operating Temperature (Max) 80°C
Reach Compliance Code compliant
Subcategory Solid State Relays
HTS Code 8541.40.95.00
Additional Feature UL RECOGNIZED, VDE APPROVED, ZERO VOLTAGE CROSSING
Terminal Finish Tin (Sn)
Pbfree Code icon-pbfree yes
JESD-609 Code e3
