CD2425D1VH
RoHS
/
Package /
Category Relays / Solid State Relays
Description
TRIGGER OUTPUT SSR 8541.40.95.00 DC RoHS Compliant Solid State Relay 80C 4V 36.3mm 0.016A
PDF
/
Inventory: 9490
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Control Voltage 4V
Output Circuit Type Back to Back SCR
Control Current 0.016A
Overall Length 58.42mm
Isolation Voltage-Max 4000V
On-State Current-Max 25A
Overall Height 36.3mm
Optoelectronic Device Type TRIGGER OUTPUT SSR
Input Type DC
Configuration SEPARATE, 2 ELEMENTS
Number of Elements 2
Operating Temperature (Min) -40°C
Operating Temperature (Max) 80°C
Reach Compliance Code compliant
Subcategory Solid State Relays
HTS Code 8541.40.95.00
Additional Feature UL APPROVED
