C347S
RoHS
RoHS compliant
RoHS compliantPackage 8-SOP (0.173, 4.40mm Width)
Category Relays / Solid State Relays
Description
SSR RELAY SPST-NO 1A 0-80V
PDF
/
Buying Options
Total Price: USD $7.87
Unit Price: USD $7.8672
≥1 USD $7.8672
≥10 USD $7.37968
≥100 USD $6.559168
≥500 USD $6.231456
≥1000 USD $5.903392
≥3000 USD $5.247475
Inventory: 1109
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Overall Length 9.7mm
Isolation Voltage 1.5kV
Load Current 1A
On-State Current-Max 1A
Overall Height 2.55mm
Max Input Current 50mA
On-State Resistance (Max) 150mOhm
Voltage - Load 0V~80V
Max Output Voltage 80V
Forward Current 50mA
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Input Type DC
Throw Configuration SPST
Voltage - Input 1.37VDC
Circuit SPST-NO (1 Form A) x 2
Number of Elements 2
Max Output Current 3A
Output Type AC, DC
Termination Style Gull Wing
Subcategory Solid State Relays
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
Termination Gull Wing
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
JESD-609 Code e3
Series COTOMOS?
Published 2012
Packaging Tube
Physical
Number of Pins 8
Package / Case 8-SOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
