PS7801-1A-F3-A

CEL
RoHS
/
Package 4-SMD (0.165, 4.20mm)
Category Relays / Solid State Relays
Description AC DC RoHS Compliant Obsolete SPST Solid State Relay 85C 1.1VDC 50mA 14Ohms
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.684
≥1 USD $2.684
Inventory: 9625
Minimum: 1
-
+

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-SMD (0.165, 4.20mm)
Number of Pins 4
Supplier Device Package 4-Ultra Small Flatlead

Technical

Packaging Cut Tape (CT)
Series PS, OCMOS
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Resistance 14Ohm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Termination Style SMD (SMT) Tab
Output Type AC, DC
Circuit SPST-NO (1 Form A)
Voltage - Input 1.1VDC
Output Current 100mA
Throw Configuration SPST
Max Output Voltage 40V
Relay Type Relay
Voltage - Load 0V~40V
On-State Resistance (Max) 14Ohms
Input Current 50mA
Load Current 100mA
Isolation Voltage 500V

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
