PS7200B-1A
RoHS
/
Package 4-SOP (0.173, 4.40mm)
Category Relays / Solid State Relays
Description
AC DC TRANSISTOR OUTPUT SSR Non-RoHS Compliant Obsolete Solid State Relay 85C 1.2VDC 0.02A 1.5Ohm
PDF
/
Buying Options
Total Price: USD $9.82
Unit Price: USD $9.824431
≥1 USD $9.824431
≥200 USD $3.920319
≥500 USD $3.789029
≥1000 USD $3.724697
Inventory: 6781
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-SOP (0.173, 4.40mm)
Number of Pins 4
Technical
Packaging Tube
Series PS, OCMOS
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Termination Style Gull Wing
Output Type AC, DC
Number of Elements 1
Circuit SPST-NO (1 Form A)
Configuration SINGLE
Voltage - Input 1.2VDC
Output Current 250mA
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Max Output Voltage 40V
Voltage - Load 0V~40V
Forward Current-Max 0.02A
On-State Resistance (Max) 1.5Ohm
Input Current 50mA
On-State Current-Max 0.25A
Isolation Voltage 1.5kV
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
