PS7160-2A

CEL
RoHS
/
Package 8-DIP (0.300, 7.62mm)
Category Relays / Solid State Relays
Description SSR RELAY SPST-NO 90MA 0-600V
PDF
/
Buying Options
Total Price: USD $20.02
Unit Price: USD $20.02125
≥1 USD $20.02125
≥10 USD $16.4274
≥100 USD $15.9144
≥500 USD $15.4014
≥1000 USD $14.88745
Inventory: 1096
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Width 6.5mm
Length 9.25mm
Height 3.5mm

Technical

Isolation Voltage 1.5kV
On-State Current-Max 0.09A
Input Current 50mA
On-State Resistance (Max) 50Ohm
Forward Current-Max 0.02A
Voltage - Load 0V~600V
Relay Type Relay
Max Output Voltage 600V
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Throw Configuration DPST
Output Current 90mA
Voltage - Input 1.2VDC
Circuit SPST-NO (1 Form A) x 2
Number of Elements 2
Output Type AC, DC
Output Voltage 600V
Termination Style PC Pin
HTS Code 8541.40.95.00
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 50Ohm
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PS, OCMOS
Packaging Tube

Physical

Number of Pins 6
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
