RP1A23D10
RoHS
/
Package 4-SIP
Category Relays / Solid State Relays
Description
Solid state relay single phase 4. . .32 VDC 10 AAC517 AAC53a, RP1A23D10, Carlo Gavazzi
PDF
/
Buying Options
Total Price: USD $23.76
Unit Price: USD $23.76
≥1 USD $23.76
≥10 USD $22.572
≥100 USD $21.384
≥500 USD $20.671288
Inventory: 114
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Length 43mm
Height 37mm
Technical
Max Input Current 10mA
Forward Current-Max 0.01A
Voltage - Load 12V~265V
Optoelectronic Device Type TRIGGER OUTPUT SSR
Turn On Delay Time 1 s
Max Voltage Rating (DC) 32V
Throw Configuration SPST
Output Current 10A
Voltage - Input 3V~32VDC
Circuit SPST-NO (1 Form A)
Number of Elements 1
Operating Supply Voltage 265V
Max Output Current 10A
Output Type AC, Zero Cross
Voltage - Rated AC 230V
Termination Style PC Pin
Depth 22mm
Additional Feature HIGH RELIABILITY, UL RECOGNIZED
Min Operating Temperature -30°C
Max Operating Temperature 80°C
Termination PCB
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series RP1A
Published 2002
Packaging Bulk
Physical
Number of Pins 4
Package / Case 4-SIP
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 6 Weeks
