RM1E23AA25
RoHS
RoHS compliant
RoHS compliantPackage Hockey Puck
Category Relays / Solid State Relays
Description
CARLO GAVAZZI RM1E23AA25 SSR, PANEL MOUNT, 280VAC, 25A
PDF
/
Buying Options
Total Price: USD $123.2
Unit Price: USD $123.2
≥1 USD $123.2
≥10 USD $117.04
≥100 USD $110.880176
Inventory: 111
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 58.2mm
Length 44.8mm
Height 28.8mm
Technical
Min Supply Voltage (AC) 90V
Max Supply Voltage (AC) 280V
Isolation Voltage 4kV
Max Input Current 20mA
Voltage - Load 90V~280V
Max Output Voltage 280V
Input Type DC
Max Voltage Rating (DC) 10V
Throw Configuration SPST
Output Current 25A
Voltage - Input 4mA~20mA
Max Voltage Rating (AC) 280V
Insulation Resistance 1GOhm
Circuit SPST-NO (1 Form A)
Output Type AC, Proportional Control
Operating Temperature (Min) -20°C
Operating Temperature (Max) 70°C
Approval Agency CE, CSA, UL
Voltage - Rated AC 230V
Termination Style Screw Terminal
Current Rating 25A
Subcategory Solid State Relays
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series RM1E
Published 2002
Packaging Bulk
Physical
Number of Pins 4
Package / Case Hockey Puck
Mounting Type Chassis Mount
Mount Panel, Screw
Contact Material Silver
Supply Chain
Factory Lead Time 12 Weeks
