RM1A23A75 image
Favorite
RM1A23A75 image
Favorite
RoHS
RoHS RoHS compliant
Package Hockey Puck
Category Relays / Solid State Relays
Description Relay;SSR;Zero-Switching;1P-NO;Cur-Rtg 75A;Ctrl-V 20-280/22-48AC/DC;Screw
PDF
/
Buying Options
Total Price: USD $92.4
Unit Price: USD $92.4
≥1 USD $92.4
≥10 USD $87.78
≥100 USD $83.160176
≥500 USD $80.388264
Inventory: 94
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 58.2mm
Length 44.8mm
Height 28.8mm

Technical

Control Current 0.01A
Max Input Current 20mA
Voltage - Load 24V~265V
Max Output Voltage 265V
Turn On Delay Time 1 s
Input Type AC/DC
Throw Configuration SPST
Output Current 75A
Voltage - Input 20V~280VAC 22V~48VDC
Insulation Resistance 1GOhm
Circuit SPST-NO (1 Form A)
Operating Supply Voltage 265V
Output Type AC, Zero Cross
Approval Agency CE, CSA, UL
Voltage - Rated AC 230V
Termination Style Screw Terminal
Current Rating 75A
Depth 58.2mm
Subcategory Solid State Relays
Min Operating Temperature -20°C
Max Operating Temperature 70°C
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series RM
Published 2007
Packaging Bulk

Physical

Number of Pins 4
Package / Case Hockey Puck
Mounting Type Chassis Mount
Mount Panel, Screw
Contact Material Silver

Supply Chain

Factory Lead Time 10 Weeks
