ASSR-5211-321E

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 6-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description RELAY SSR SPST SGL 0.2A 6SMD GW
PDF
/
Buying Options
Total Price: USD $2.89
Unit Price: USD $2.88838
≥1 USD $2.88838
≥200 USD $1.118591
≥500 USD $1.079204
≥1000 USD $1.05951
Inventory: 1764
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 17 Weeks

Physical

Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD (0.300, 7.62mm)
Number of Pins 6

Technical

Packaging Tube
Published 2013
Series ASSR
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
ECCN Code EAR99
Resistance 16Ohm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature CMOS COMPATIBLE, UL RECOGNIZED
HTS Code 8541.40.80.00
Termination Style Gull Wing
Output Type AC, DC
Max Output Current 200mA
Number of Elements 1
Circuit SPST-NO (1 Form A)
Voltage - Input 1.3VDC
Output Current 200mA
Throw Configuration SPST
Input Type DC
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Max Output Voltage 600V
Relay Type Relay
Voltage - Load 0V~600V
Forward Current-Max 0.02A
On-State Resistance (Max) 16Ohm
Max Input Current 20mA
Overall Height 4.7mm
Input Current 20mA
On-State Current-Max 0.2A
Isolation Voltage 5kV
Control Current 0.003A

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
