ASSR-322R-302E
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
SSR RELAY SPST-NO 200MA 0-250V
PDF
/
Buying Options
Total Price: USD $21.15
Unit Price: USD $21.1508
≥1 USD $21.1508
≥10 USD $17.3546
≥100 USD $16.81215
≥500 USD $16.2697
≥1000 USD $15.72725
Inventory: 5405
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SMD (0.300, 7.62mm)
Number of Pins 8
Technical
Packaging Tube
Published 2013
Series ASSR
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
ECCN Code EAR99
Resistance 8.5Ohm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Voltage - Rated DC 250V
Termination Style Gull Wing
Output Voltage 250V
Output Type AC, DC
Max Output Current 200mA
Number of Elements 2
Circuit SPST-NO (1 Form A) x 2
Voltage - Input 1.3VDC
Output Current 200mA
Throw Configuration DPST
Input Type DC
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Forward Current 20mA
Max Output Voltage 250V
Max Input Voltage 1.65V
Relay Type Relay
Voltage - Load 0V~250V
RMS Current (Irms) 200mA
On-State Resistance (Max) 8.5Ohm
Max Input Current 20mA
Overall Height 4.2mm
Input Current 20mA
On-State Current-Max 0.2A
Isolation Voltage 3.75kV
Overall Length 9.65mm
Control Current 0.003A
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
